Specifications
| Center width | 150 mm |
| Centre height | 100 mm |
| Workpiece diameter | < 150 mm |
| Workpiece weight | 50kg |
| Load when working with a chuck | 100 Nm |
| Supply voltage | 400 V / 460 V |
| Power consumption depending on the equipment | 35 A – 63 A |
| Length x width | 1.8m x1.8m |
| Total weight | 3’000 kg |
Table / slide Z-axis
| Travel range | 300 mm |
| Feed rate Speed | 20 000 mm/min |
| Scale resolution | 0.1 µm |
Cross slide X-axis
| Travel range | 325 mm |
| Feed rate Speed | 18 000 mm/min |
| Scale resolution | 0.1 µm |
Turned parts B1
| Swivel range | n/a |
| Swivel speed | n/a |
| Automatic indexing Resolution | n/a |
| Encoder resolution | n/a |
Turned parts B2
| Automatic indexing Resolution | n/a |
| Swivel speed | n/a |
| Swivel range | n/a |
| Encoder resolution | n/a |
Grinding head
| Type | Parallel |
External grinding
| Grinding wheel dimensions | n/a |
| Drive motor Water-cooled | n/a |
| Power Peripheral speed | n/a |
Internal grinding
| Bore of the holder | Ø 100 mm |
| max. power HF spindles | 7.5 kW |
| max. rotational speeds | 120 000 U/min |
| Rapid traverse X-axis | 15 m/min |
| Rapid traverse Z-axis | 20 m/min |
Workpiece headstock
| Type | Direct 50 |
| Speed range | 3’000 min-1 |
| Mounting cone | MK 4 |
| External short taper ISO 702-1 | Gr. 3 |
| Encoder resolution | n/a |
| Roundness accuracy for fly grinding | 0.4 / 0.2 μm |
| Precision adjustment | ± 1.5″ |
Tailstock
| Mounting cone | n/a |
| Stroke | n/a |
| Precision adjustment | n/a |
CNC control
| Manufacturer / Type | Fanuc 0i-F |
Machine operation
| HMI | BLUE Solution |
Software modules
| Tool management | Option |
| Global dresser | Option |
| Global calibration | Option |
| Out of round grinding | n.a. |
| Measurement of tool holder with gSET | n.a. |
| gSHAPE (with DXF import) | n.a. |
| AppOutOfRound (CAPTO) | n.a. |
| Tool correction | Option |
| Tool type Cup wheel | Option |
| Out of round grinding | n.a. |
| Jig grinding | n.a. |
